For the most demanding applications we present SoliFelt™ ZR-grade, with a classification temperature of 1430°C. It provides a proven solution in applications operating continuously up to 1300°C. Like the rest of the range it is a latex bonded fiber board product that remains flexible after production, combining the strength of a board with the resiliency needed to ensure a mechanical seal.
The SoliFelt™ product range consists of latex bonded fiber board products which remain flexible after production. As a result, SoliFelt™ can be used in applications where the end user requires the strength of a board product with the flexibility and resiliency to ensure a mechanical seal.
For the most demanding applications we proudly present SoliFelt™ ZR-grade, with a classification temperature of 1430°C. As a result it provides a proven solution in applications operating continuously up to 1300°C. The maximum continuous use temperature is a guideline and only applicable in a clean oxidizing atmosphere.
All SoliFelt™ products are manufactured from true Generation III, ultra clean and fine SoliWool fiber and organic binders. As a result SoliFelt™ has a very smooth surface, close dimension tolerances, exceptionally low dust, high handling strength, better thermal insulating performance and greater resiliency after compression thanks to the superior fiber index.
| Properties measured | Standard | Unit | SoliFelt ZR-grade |
|---|---|---|---|
| Grade | RCF | ||
| Colour | off-white | ||
| Classification temperature | °C | 1430 | |
| Continuous use temperature | °C | 1300 | |
| Density | kg/m3 | 160 | |
| Loss on ignition | wgt% | < 8 | |
| Permanent linear shrinkage | EN 1094-7 | % | |
| @1400°C | < 3 | ||
| Thermal conductivity | ASTM C201 | W/mK | |
| @200°C | 0,06 | ||
| @400°C | 0,09 | ||
| @600°C | 0,14 | ||
| @800°C | 0,20 | ||
| @1000°C | 0,27 | ||
| Chemical composition (after firing) | ISO 12677 | % | |
| SiO2 | 48 - 51 | ||
| Al2O3 | 34 - 37 | ||
| ZrO2 | 14 - 17 | ||
| Other | < 1 |
SoliFelt™ is available in standard dimensions of 1200×1000 mm, supplied in carton boxes with a height of approximately 120 mm, based on thickness. Please refer to the list below for packaging details of SoliFelt™ in the standard carton boxes.
Other sizes are available on request. For additional information about product performance or to identify the recommended product for your application, please contact the team at Vulcor Insulation.
| Length (mm) | Width (mm) | Thickness (mm) | Per carton box | Boards per pallet |
|---|---|---|---|---|
| 1200 | 1000 | 6 | 20 | 320 |
| 1200 | 1000 | 10 | 12 | 192 |
| 1200 | 1000 | 13 | 10 | 160 |
| 1200 | 1000 | 19 | 6 | 96 |
| 1200 | 1000 | 25 | 5 | 80 |
